R3

Specifications

Engine

• Engine Type: 4-stroke, 2-cylinder, Liquid-cooled, DOHC, 4-valves
• Displacement: 321cc
• Bore & Stroke: 68.0 mm x 44.1 mm
• Compression Ratio: 11.2 : 1
• Maximum Power: 30.9 kW (42.0 PS) @ 10,750 rpm
• Maximum Torque: 29.5 Nm (3.0 kgfm) @ 9,000 rpm
• Clutch Type: Wet, Multiple Disc
• Ignition System: Electric
• Starter System: TCI
• Transmission System: Constant Mesh, 6-speed
• Fuel System: Fuel Injection

Dimensions

• Overall Length: 2,090 mm
• Overall Width: 730 mm
• Overall Height: 1,140 mm
• Minimum Ground Clearance: 160 mm
• Wet Weight (Including full oil and fuel tank): 169 kg
• Seat Height: 780 mm
• Wheelbase: 1,380 mm
• Fuel Tank Capacity: 14 L

Chassis

• Frame Type: Diamond
• Caster Angle: 25°
• Trail: 95 mm
• Front Suspension System: Telescopic Upside Down Fork (USD Fork)
• Rear Suspension System: Swingarm
• Front Brake: Hydraulic single disc, 298 mm
• Rear Brake: Hydraulic single disc, 220 mm
• Front Tyre: 110/70 R17M/C 54H Tubeless
• Rear Tyre: 140/70 R17M/C 66H Tubeless
• ABS: Dual Channel

Other Info

• Battery: 12 V, 7.0 Ah
• Headlight: Dual LED
• Position Light: LED
• Brake/Tail Light: LED
• Speedometer: Digital
• Tachometer: Digital
• Fuel Meter: Digital
• Fuel Consumption Indicator: Equipped
